Features

• 250Hz: Fastest available radio and telemetry link
• Brand new 2.4GHz technology not found in any other radio link
• 3ms end to end latency
• Crossfire engine for ultimate compatibility and functionality
• "JR" and "LITE" form factor transmitters
• Nano-sized receiver with antenna diversity
• 15mi+/25km+ range
• For drones, planes, helicopters, cars and boats

All product features at team-blacksheep.com

Specifications

Latency & Refresh Rate: 3ms, 250Hz
Output power: 25mW / 100mW
Frequency Bands: 2.4GHz ISM
Input Voltage: 5V - 9V
Connector: USB-C
Power consumption: 1.1W (@10mW) - 2W (@100mW)
Dimensions: 65 x 48 x 22 mm (JR module size)
Radio Compatibility: Lite module bay (e.g. TBS Tango 2, Taranis X-Lite, X9 Lite), OpenTX V2.1+. The TBS Tracer Nano TX is suggested for use in Futaba and Spektrum remotes that do not have a JR-module bay

* output power modes may not be available due to local regulation limitations

Downloads

• TBS Tracer Manual (PDF)
• TBS Agent X (for software updates)
• Latest OpenTX LUA scripts for crossfire
