Lens options

• 1.8mm​ lens (M8)​ ​- FOV160°
• 2.1mm lens (M8) - FOV145°

Features

• Ultra low latency - 6ms
• Super WDR CMOS sensor
• Switchable UART / Joystic control
• Switchable 4:3 / Widescreen aspect ratio
• OSD with VBat display for easy builds
• Durable - robust camera case
• Lightweight - with M8 lens

Specs

• Image Sensor: Super WDR CMOS Sensor
• Horizontal Resolution: 1000TVL
• Lens: 1.8mm FOV 160° / 2.1mm FOV 145°
• Screen Format: 4:3 / Widescreen Switchable
• Signal System: NTSC / PAL Switchable
• Mirror/Flip: Available
• Integrated OSD: Yes
• One Touch Scene Setting: Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight
• S/N Ratio: > 50dB
• Electronic Shutter Speed: Auto
• Min. Illumination: 0.01Lux@1.2F
• WDR: Super WDR
• Day/Night: Auto
• Menu Control: Joystick Control / UART Control Switchable
• Power: DC 5-36V
• Current: 110mA @ 5V / 40mA @ 12V
• Housing Material: ABS
• Net Weight: 6g
• Dimensions: 19 x 19 x 18 mm

Includes

1x Camera
1x 1928 ABS bracket
1x 2 set of screws
1x 6pin FPV silicone cable
1x Manual

User manual (PDF)
