FC Specifications

• MCU: 216MHz STM32F722RET6
• IMU: MPU6000 & ICM20602, Dual Gyros built-in (SPI)
• Baro: BMP280 (I2C)
• OSD: AT7456E (SPI)
• Blackbox: MicroSD card slot (SPI)
• 5x Uarts (1,2,3,4,6) with built-in inversion
• 1x Softserial supported
• 8x Dshot/Proshot/oneshot outputs
• 1x I2C
• 4x RX6 pad(one per cornet) for BLheli32 ESC telemetry
• 4x individual ESC power/signal pads
• 1x Group of  G/S1/S2/S3/S4 pads for 4in1 ESC Signal/GND
• 3x LEDs for FC STATUS (Blue, Green) and 3.3V indicator(Red)
• Vbat filtered output power for VTX,  Switchable via AUX (modes tab-user1)
• Dual Camera image switchable via AUX (modes tab-user2)
• Camera control: Yes
• Smartaudio & Tramp VTX protocol: Yes
• WS2812 Led Strip : Yes
• Beeper : Yes
• RSSI: Yes
• Additional ADC for INAV analog airspeed

PDB Specifications

• Input: 6~36V (3~8S LiPo) w/TVS protection
• PDB: 4x35A (Max.4x46A)
• BEC: 5V 2A cont. (Max.3A)
• LDO 3.3V: Max.200mA
• Current Sensor 184A (Scale 179)
• Battery Voltage Sensor: 1:10 (Scale 110)

Physical

• Mounting: 30.5 x 30.5mm, Φ4mm with grommets Φ3mm
• Dimensions:  36 x 46 mm
• Weight: 10g

Firmware support

BetaFlight / INAV
Target: MATEKF722SE

Included

1x FC F722-SE
6x silicon grommets M4 to M3
1x FR4 PCB Plate 36*36*1mm
1x Rubycon ZLH 35V/470uF (Low ESR)
